USB-AD-OEM
€ 129.00
made_in_germany

Really Simple.

Record and output signals with the USB-AD: The USB data acquisition system is ideal for universal applications in measurement and control technology. Implement your own ideas – just plug in and head off!

OEM. Compact. Powerful. Budget Price.

The idea behind the USB-AD-OEM: measuring whre there is very little space. Mounting holes like2,5“ HD/SSD mean you can mount the USB-AD- OEMin a PC or any other housing.

16 AIn. 1 AOut. 12 Bit. ±5V.

Voltage signals in the ± 5V range are connected to 16 analog inputs. The sampling takes place with 12 bit resolution and up to 800Hz total sampling rate. Analog controls are possible with the analog 12-bit output in the ± 5V output range.

16 Digital In-/Outputs.

Digital states are recorded or controlled at four digital inputs and outputs each. Digital inputs are sampled time-synchronously with the analog inputs.

Plug & Play.

The connection to the PC happens via USB. That way the USB-AD-OEM uses all USB-typical features (eg. Plug & Play, Hot-Plug). Up to 127 devices can be connected and installed during operation.

Powered by USB.

The device is powered by the USB interface. This reduces the wiring effort to a minimum.

Ideal for Windows

The data acquisition system can be used under Windows 8.1 and 10 in 64bit. The complete software for installation and programming is provided for free.

NextView. Try for Free.

The DAQ system is supported by NextView, the software for data acquisition and analysis. A fully functional 14-day trial can be requested under www.nextview.de. So it is possible, to directly test the functionality of the device.

The most important functions in a nutshell. For technical details see the relating data sheet (PDF).

  •   16 analog inputs (12 bit, max. 10Hz/channel, ±5V)
  •   1 analog output (12 bit, ±5V)
  •   16 digital I/O lines (TTL/CMOS)
  •   bus-powered
  •   USB 2.0, full-speed
  •   DAQ system with 2,5“ HD/SSD mounting holes

Hardware and Software from One Hand

Drivers and programming support are naturally included with all DAQ systems for free and can be downloaded from this website.

bmcm Driver Package

USB/PCI/PCIe data acquisition hardware always requires the installation of a device driver to be accessible by software. By providing a free bmcm driver package, the device installation has to be done only once - additional DAQ hardware is installed automatically.

Simply NextView

For all who want to start right away: View and store signals, configure the measurement system, process measuring data and much more.
Test all features of the data ac­qui­sition software 14 days for free! As a premium member of bmcm you can test all functionalitys of NextView for 30 days.
Next...

Simply LIBAD

Programming leanly and quickly: Use bmcm data acquisition systems in your own programs. The hardware independent programming interface (API) LIBAD4 is available as DLL in 64 Bit (Windows 8.1/10).
Next...
