For Measuring Amplifiers and Sensors. Get Connected.

Backplane for miniature amplifiers: Up to sixteen measuring amplifiers, converters, or any other function modules can be integrated in the BP16. If installed close to the signal, it provides for high interference resistance. Ideal for remote signal conditioning of passive sensors.

Signal Conditioning in Miniature Format.

In type of construction, the cost-effective MAL modules are designed like a 24-pin DIL IC. Measurement applications can therefore be realized even in problematic locations. With suitable measuring amplifiers, multiple wire technique can be realized, too.

Optimally Supplied.

The BP16 is operated with 9-30V or 5V. The integrated amplifiers are supplied by the electrically isolated power supply. In addition, 5V (120mA) with galvanic isolation are provided for sensor supply.

Signal Connection. D-Sub Standard.

Sensors or other voltage signals can comfortably be connected at a 37-pin D-Sub female.

Connection to the DAQ System.

The amplifier outputs are available at a 37-pin D-Sub female connector. They are connected to the input lines of a data acquisition system. Combining the BP16 with a measuring card or DAQ system from bmcm makes an extreme compact measurement system.

External Device.

The BP16 is accommodated in a stable aluminum housing ideal for mobile use. Notches in the housing frames allow for fixing the BP16 to a DAQ system (e.g. USB-AD14f) providing for a stable measuring unit.

The Smaller Options. You Have the Choice.

For all needing less channels: The backplane for miniature amplifiers is also available as a 2-channel version with carrier for DIN rail mounting (BP2) or integrated in a waterproof IP65 housing (BP2-BOX).

The most important functions in a nutshell. For technical details see the relating data sheet (PDF).

  •   16 DIL sockets for MAL amplifiers
  •   compatible to DAQ systems from bmcm
  •   signal connection at 37-pin D-Sub female
  •   amplifier outputs at 37-pin D-Sub female
  •   power supply directly by bmcm device or externally with 9..30V

BP2

BP2
Amplifier backplane for 2x MAL modules
 69.00

BP2-BOX

BP2-BOX
Amplifier backplane for 2x MAL modules with housing
 99.00

MAL-FU

MAL-FU
Miniature frequency to voltage converter
 99.00

MAL-PT100

MAL-PT100
Miniature measuring amplifier (PT100, -60..300°C)
 99.00

MAL-I20mA

MAL-I20mA
Miniature measuring amplifier (current, ±20mA)
 59.00

MAL-THR

MAL-THR
Miniature measuring amplifier (thermocouple, type K)
 99.00

MAL-U Series

MAL-U10
Miniature measuring amplifiers (voltage, ±10V, ±5V, ±1V))
 59.00

ZU-TR

ZU-TR
Temp. reference sensor at D-Sub 37 male (for BP16 with MAL-THR)
 12.00

ZU-PW40W

ZU-PW40W
Desktop power supply (24V, 40W)
 59.00

ZU-SCHI

ZU-SCHI
Wall or DIN rail fastening kit
 12.00

ZU37BB

Connector panel (16x BNC, 37x 4mm banana jacks)
 159.00

ZU37CB

Connector panel (18x terminal connectors, 37x banana jacks)
 159.00

ZU37CO

Connector panel (18x terminal connectors)
 99.00

MAL-ISO Line

MAL-ISO50
Isolating measuring amplifiers (±50V, ±10V, ±5V, ±1V, 20mA)
 99.00

MAL-SG Line

MAL-SG2
Miniature measuring amplifier (strain gauge, +/-2mV or +/-5mV)
 99.00

ZUKA37 Line

ZUKA37SB
D-Sub 37 connecting cable (male/female or male/male)
 29.00
