MAL-ISO Line
 79.00
MAL-ISO50
MAL-ISO50
MAL-ISO10
MAL-ISO5
MAL-ISO1
MAL-ISO20mA
MAL-ISO1 oben
MAL-ISO1 unten
MAL-ISO rechts
MAL-ISO links
MAL-ISO Front/Rückseite
MAL-Miniaturmessverstärker
Blockdiagramm

Perfectly Conditioned. Isolated.

Voltage (MAL-ISO50/10/5/1) and current signals (MAL-ISO20mA) can optimally be adjusted to the input of a data acquisition system with the differential amplifiers MAL-ISO. The isolation of the analog inputs guarantees reliable measurement results.

Minimum Size. Great Performance. Small Price.

The miniature format of the MAL-ISO is ideal to realize measurement applications even if the installation is in problematic locations. Despite the small size, the measuring amplifier features great functionality. All this at a reasonable price.

Clearly Safe.

The galvanic isolation provided by the isolation amplifiers guarantees interference-free operation and protects the DAQ system and the PC against high potentials.

Voltage or Current.

The amplifier types differ in their input voltage range of ±1V up to ±50V (MAL-ISO50/10/5/1) for voltage measurement and ±20mA (MAL-ISO20m) for current measurement.
A ±5V signal proportional to the input signal is provided at the output.

Compatibility.

The MAL series provides a great variety of measuring amplifiers, measuring converters, or filter modules. They can be used in any combination allowing for the solution of the most individual measuring tasks.

Get Connected.

With the backplanes of the BP series varying in size and design, signal connection is easy. The modules just have to be plugged on the relevant slot of the backplane.

The most important functions in a nutshell. For technical details see the relating data sheet (PDF).

  •   size: 24-pin DIL IC
  •   50Hz bandwidth
  •   differential input
  •   measured quantities: voltage, current
  •   MAL-ISO50: ±50V
  •   MAL-ISO10: ±10V
  •   MAL-ISO5: ±5V
  •   MAL-ISO1: ±1V
  •   MAL-ISO20mA: ±20mA
  •   output filter 6dB/oct.
