MAL-PT1000
 99.00
MAL-PT1000 oben
MAL-PT100 unten
MAL-PT1000 rechts
MAL-PT1000 links
MAL-PT1000 Front/Rückseite
MAL-Miniaturmessverstärker
Blockdiagramm
made_in_germany

Perfectly Conditioned. Temperature.

Resistance signals of a PT100 sensor can optimally be adjusted to the input of a PC data acquisition system with the miniature measuring amplifier MAL-PT100. A perfect solution for temperature measurements in the range of -60..300°C. A 1mA sensor supply is provided for connected sensors.

Minimum Size. Great Performance. Small Price.

The miniature format of the MAL-PT100 is ideal to realize measurement applications even if the installation is in problematic locations. Despite the small size, the measuring amplifier features great functionality. All this at a reasonable price.

Resistance Measurement. Linearization. Amplification.

The MAL-PT100 measures the resistance of a PT100 sensor. As the signal values of the sensor are not linear, the MAL-PT100 takes care of linearization providing a proportional voltage in the range of -1..5V at the output.

2-, 3-, or 4-Wire Technology.

Depending on the demands concerning measuring accuracy, 2-, 3-, or 4-wire measurement is possible with the MAL-PT100. Very easy to configure with solder jumpers on the measuring amplifier.

Compatibility.

The MAL series provides a great variety of measuring amplifiers, measuring converters, or filter modules. They can be used in any combination allowing for the solution of the most individual measuring tasks.

Get Connected.

With the backplanes of the BP series varying in size and design, signal connection is easy. The modules just have to be plugged on the relevant slot of the backplane.

The most important functions in a nutshell. For technical details see the relating data sheet (PDF).

  •   size: 24-pin DIL IC
  •   80Hz bandwidth
  •   differential input
  •   measured quantities: temperature (PT100), -60..300°C
  •   linearization
  •   sensor supply 1mA
  •   output filter 6dB/oct.

MAL-FU

MAL-FU
Miniature frequency to voltage converter
 99.00

MAL-I20mA

MAL-I20mA
Miniature measuring amplifier (current, ±20mA)
 59.00

MAL-THR

MAL-THR
Miniature measuring amplifier (thermocouple, type K)
 99.00

MAL-SG Line

MAL-SG2
Miniature measuring amplifier (strain gauge, +/-2mV or +/-5mV)
 99.00

MAL-U Series

MAL-U10
Miniature measuring amplifiers (voltage, ±10V, ±5V, ±1V))
 59.00

MAL-ISO Line

MAL-ISO50
Isolating measuring amplifiers (±50V, ±10V, ±5V, ±1V, 20mA)
 99.00

MAL-PT100

MAL-PT100
Miniature measuring amplifier (PT100, -60..300°C)
 99.00

BP2

BP2
Amplifier backplane for 2x MAL modules
 69.00

BP2-BOX

BP2-BOX
Amplifier backplane for 2x MAL modules with housing
 99.00

BP16

BP16
Amplifier backplane for 16x MAL modules with housing
 259.00
