MAL-U Series
 49.00
MAL-U10
MAL-U10
MAL-U5
MAL-U1
MAL-U10 oben
MAL-U10/5/1 unten
MAL-U10/5/1 rechts
MAL-U10/5/1 links
MAL-U10/5/1 Front/Rückseite
MAL-Miniaturmessverstärker
Blockdiagramm
made_in_germany

Perfectly Conditioned. For Voltage.

Voltage signals can optimally be adjusted to the input of a PC data acquisition system with the miniature measuring amplifiers MAL-U10, MAL-U5, and MAL-U1. They feature a 5V sensor supply for connected sensors.

Minimum Size. Great Performance. Small Price.

The miniature format of the MAL-U10/5/1 is ideal to realize measurement applications even if the installation is in problematic locations. Despite the small size, the measuring amplifier features great functionality. All this at a reasonable price.

±10V, ±5V, ±1V IN. ±5V OUT.

The amplifier types differ in their input voltage range of ±10V (MAL-U10), ±5V (MAL-U5), and ±1V (MAL-U1).
A ±5V signal proportional to the input signal is provided at the output.

Compatibility.

The MAL series provides a great variety of measuring amplifiers, measuring converters, or filter modules. They can be used in any combination allowing for the solution of the most individual measuring tasks.

Get Connected.

With the backplanes of the BP series varying in size and design, signal connection is easy. The modules just have to be plugged on the relevant slot of the backplane.

The most important functions in a nutshell. For technical details see the relating data sheet (PDF).

  •   size: 24-pin DIL IC
  •   50Hz bandwidth
  •   differential input
  •   measured quantities: voltage
  •   MAL-U10: ±10V
  •   MAL-U5: ±5V
  •   MAL-U1: ±1V
  •   sensor supply 5V
  •   output filter 6dB/oct.
