Visualize. Configure. Scan. Analyze.

One software for everything. NextView 5 covers the entire world of PC measurement data acquisition: displaying live data, recording measured values, analyzing your measurement applications – and even much more.

Versions. Something for Everyone.

Full functionality, a version with basic functions, or rather an analysis version without DAQ hardware? With NextView 5 Pro, Lite, or Analysis, you will find what meets your needs. You are free to test the complete function range of the software for 14 days.

Upgrade. If You Want More.

For holders of a NextView 4.x license, the discounted version NV5-UG is a great possibility to upgrade to the latest NextView 5 release with extremely extended features, ease of use, and support of the currently available bmcm DAQ hardware.

Application-Oriented. No Programming.

NextView 5 puts a main focus on user friendliness and practical use. An intuitive operating concept (e.g. Drag & Drop) guarantees extremely short training periods to get results fast. Programming skills are not necessary.

Measurement Hardware.

NextView 5 supports all currently available DAQ systems of bmcm. Several devices are represented as one measuring system.

Show Signals. Live or Recorded.

Analog and digital signals provided by the DAQ hardware can be shown online as graphs, numerical values, or levels. Display and analysis of measuring data stored or imported in a file is done in a graph display.

Control & Automate.

NextView 5 features switches, push-buttons, and sliders to control analog and digital outputs. With the add-on module NextView 5 Script, it is possible to automate processes or realize individual applications. In case of alarm, for example, an event can be set off, which has been programmed with the BASIC-like script language.

MultiScan. Trigger. Prehistory.

Ideal for long-term measurements and interference monitoring. The MultiScan creates single files (back-to-back), which are already available for analysis while the scan is still running. If a trigger – optionally with prehistory – has been set, measured data are only stored for a defined period of time when or before the trigger event occurred.


Use the FileTrain function to reconnect these files. This is necessary for analyses beyond file limits, for example.

The most important functions in a nutshell. For technical details see the relating data sheet (PDF) or visit the NextView website.

  •   unlimited number of DAQ systems, 16 formula channels
  •   storage type: current value, average, minimum, maximum, r.m.s.
  •   MultiScan & FileTrain, trigger & prehistory
  •   displays: live display, graph display, digital multimeter, level indicator, picture, static text
  •   display functions: zoom, scroll, cursors, x/y-representation
  •   control instruments: (push-)button, slider
  •   analysis: integration, differentiation, FFT, digital filters, calculate signals and signal parameters
  •   access control: lock projects
  •   other functions: alarm, export, import, print and many more


NextView 5 Professional (single license)


NV Analyse
NextView 5 Analysis (single license)


NV Lite
NextView 5 Lite (single license)


NV Script
NextView 5 script option
