Visualize. Configure. Scan. Analyze.

One software for everything. NextView 5 covers the entire world of PC measurement data acquisition: displaying live data, recording measured values, analyzing your measurement applications – and even much more.

Versions. Something for Everyone.

Full functionality, a version with basic functions, or rather an analysis version without DAQ hardware? With NextView 5 Pro, Lite, or Analysis, you will find what meets your needs. You are free to test the complete function range of the software for 14 days.

Upgrade. If you want more.

For holders of a NextView 4.x Analysis license, the discounted version NV5AN-UG is a great possibility to upgrade to the latest NextView 5 Analysis release with extremely extended features and ease of use.

Application-Oriented. No Programming.

NextView 5 puts a main focus on user friendliness and practical use. An intuitive operating concept (e.g. Drag & Drop) guarantees extremely short training periods to get results fast. Programming skills are not necessary.

Show Recorded Signals.

Recorded or imported measuring data stored in a file can be viewed and analyzed in the so-called graph display.

Control & Automate.

With the add-on module NextView 5 Script, it is possible to automate processes or realize individual applications. In case of alarm, for example, an event can be set off, which has been programmed with the BASIC-like script language.


The MultiScan function provided by the Professional version creates single files (back-to-back), which are already available for analysis while the scan is still running. Use the FileTrain function to reconnect these files. This is necessary for analyses beyond file limits, for example.

The most important functions in a nutshell. For technical details see the relating data sheet (PDF) or visit the NextView website.

  •   displays: graph display, picture, static text
  •   display functions: zoom, scroll, cursors, x/y-representation
  •   control instruments: (push-)button
  •   analysis: integration, differentiation, FFT, digital filters, calculate signals and signal parameters
  •   access control: lock projects
  •   other functions: FileTrain, export, import, print and many more


NextView 5 Professional (single license)


NV Analyse
NextView 5 Analysis (single license)


NV Lite
NextView 5 Lite (single license)


NV Script
NextView 5 script option
