NV5AN
 399.00
NV Analyse
NV Analyse
NV Signale
made_in_germany

Visualize. Configure. Scan. Analyze.

One software for everything. NextView 5 covers the entire world of PC measurement data acquisition: displaying live data, recording measured values, analyzing your measurement applications – and even much more.

Versions. Something for Everyone.

Full functionality, a version with basic functions, or rather an analysis version without DAQ hardware? With NextView 5 Pro, Lite, or Analysis, you will find what meets your needs. You are free to test the complete function range of the software for 14 days.

Process Recorded Data. Get Results.

The version NV5AN comprises the entire analysis field of NextView 5. Recorded signals or imported measuring files are visualized as curves in a graph display. Benefit from the manifold display and analysis functions of the software and achieve reliable measuring results.

Application-Oriented. No Programming.

NextView 5 puts a main focus on user friendliness and practical use. An intuitive operating concept (e.g. Drag & Drop) guarantees extremely short training periods to get results fast. Programming skills are not necessary.

Show Recorded Signals.

Recorded or imported measuring data stored in a file can be viewed and analyzed in the so-called graph display.

Control & Automate.

With the add-on module NextView 5 Script, it is possible to automate processes or realize individual applications. In case of alarm, for example, an event can be set off, which has been programmed with the BASIC-like script language.

FileTrain.

The MultiScan function provided by the Professional version creates single files (back-to-back), which are already available for analysis while the scan is still running. Use the FileTrain function to reconnect these files. This is necessary for analyses beyond file limits, for example.

The most important functions in a nutshell. For technical details see the relating data sheet (PDF) or visit the NextView website.

  •   displays: graph display, picture, static text
  •   display functions: zoom, scroll, cursors, x/y-representation
  •   control instruments: (push-)button
  •   analysis: integration, differentiation, FFT, digital filters, calculate signals and signal parameters
  •   access control: lock projects
  •   other functions: FileTrain, export, import, print and many more

NV5

NV PRO
NextView 5 Professional (single license)
 999.00

NV5AN-UG

NV Analyse Upgrade
NextView 5 Analysis upgrade (NV4-AN -> NV5AN)
 249.00

NV5LITE

NV Lite
NextView 5 Lite (single license)
 249.00

NV5SCRIPT

NV Script
NextView 5 script option
 399.00
